Type (N)SHTOEU 0.6/1KV – Innovative Reeling Cable for E-RTG Power Distribution
Designed to Withstand Severe Mechanical and Environmental Stress with Integrated Fibre-Optic Data for Modern Port Automation
CORDAFLEX XPRT (N)SHTOEU cable is an advanced, flexible low voltage reeling cable engineered specifically for the demanding power supply requirements of Electrified Rubber Tyred Gantry (E-RTG) cranes and similar mobile industrial systems.
Designed to excel under high and very high mechanical stresses, this cable not only ensures reliable electrical performance but also offers optional integrated fiber-optic data transmission for real-time monitoring and automation in port and shipyard environments.
Key Technical Attributes and Construction
This cable is constructed with very finely stranded, tinned copper (Class FS) conductors, which provide exceptionally low electrical resistance and enhanced conductivity. It features a three-core design with a split earth conductor that ensures balanced power distribution and minimizes interference.
Where required, an integrated optical element is placed within the interstices; this consists of six optical tubes, each capable of housing one to four optical fibers, enabling high-speed data communication alongside power delivery.
The core insulation is manufactured from premium EPR rubber (PROTOLON MS), enhanced with a special compound (>3GI3) for superior dielectric strength and durability. The cable’s protective structure includes an inner sheath made from high-quality polychloroprene (PCP) (PROTOFIRM with a compound >5GM5), and a matching outer sheath that offers excellent resistance to oil, UV radiation, ozone, and seawater.
In addition, polyester braiding reinforcement significantly increases its mechanical strength, ensuring the cable can withstand repeated roller bending, reversed bending, and torsional stress.
Environmental and Thermal Performance
Designed for extreme operational conditions, the CORDAFLEX cable is capable of enduring ambient temperatures from -50°C to +80°C for fixed installations and -35°C to +80°C in flexible applications. It maintains a continuous conductor temperature of up to 90°C and can safely withstand short-circuit conditions reaching 250°C. Its robust construction is critical for use in harsh maritime climates, where exposure to corrosive saltwater, intense UV rays, and industrial chemicals is common.
Compliance and Certification
Manufactured to rigorous standards, this cable adheres to:
DIN VDE 0250-814
VDE Reg. Nr. 7519
DIN VDE 0298-3
DIN VDE 0207-20/21
DIN VDE 0295 / DIN EN 60228 / IEC 60228
DIN VDE 0298-4
DIN EN 60811-404 / IEC 60811-404
DIN EN 60332-1-2 / IEC 60332-1-2
These certifications validate its electrical safety, mechanical robustness, and flame retardant properties, ensuring that the cable meets global industry standards.
Ideal Applications
The CORDAFLEX XPRT (N)SHTOEU 0.6/1KV cable is the perfect solution for E-RTG cranes used in automated container terminals and port operations. Its ability to deliver stable power while withstanding intense mechanical stress makes it equally suited for shipyard applications and other industrial settings where equipment is subject to rapid movement, frequent bending, and severe torsional loads.
Why Choose CORDAFLEX XPRT (N)SHTOEU?
Enhanced Flexibility and Durability: Designed to handle extreme mechanical stress and continuous reeling without performance degradation.
Integrated Data Capability: Optional fiber-optic integration supports real-time monitoring and automation, crucial for modern port operations.
Robust Environmental Resistance: Oil-resistant, UV-stable, ozone-proof, and seawater-resistant – built to perform in the most challenging maritime and industrial conditions.
Certified Reliability: Meets a comprehensive range of international standards ensuring both electrical efficiency and operational safety.
This detailed product introduction is crafted to provide clear and valuable information for professionals in the cranes and material handling industry, ensuring that the CORDAFLEX XPRT (N)SHTOEU 0.6/1KV cable stands out as a premier choice for powering and data-integrating critical systems in demanding port, shipyard, and industrial environments.
Frequently Asked Questions (FAQ)
Q: What is the primary purpose of the CORDAFLEX XPRT (N)SHTOEU cable?
A: It is engineered to provide reliable low voltage power for E-RTG cranes and other mobile industrial equipment, ensuring continuous operation in challenging environments.
Q: What is the nominal voltage rating of this cable?
A: The cable is rated at 0.6/1KV, making it ideal for low voltage applications where safety and efficiency are critical.
Q: What type of conductor is used in this cable?
A: It utilizes very finely stranded, tinned copper (Class FS) conductors to achieve minimal electrical resistance and high conductivity.
Q: What material is used for core insulation?
A: The core is insulated with EPR rubber (PROTOLON MS) enhanced with a special compound (>3GI3), offering exceptional dielectric strength and durability.
Q: How is the cable’s core designed?
A: It features a three-core design with a split earth conductor, ensuring balanced power distribution and improved safety.
Q: Does this cable support integrated data transmission?
A: Yes, it can include an optional integrated optical element with six optical tubes, each capable of housing multiple fibers for high-speed data communication.
Q: What is the inner sheath made of?
A: The inner sheath is constructed from polychloroprene (PCP) rubber (PROTOFIRM) with a special compound (>5GM5) to enhance mechanical protection.
Q: What reinforcement does the cable have?
A: It is reinforced with polyester braiding, providing additional mechanical strength and resistance to impact.
Q: What are the characteristics of the outer sheath?
A: The outer sheath is also made from high-grade polychloroprene (PCP), offering excellent resistance to oil, UV, ozone, and seawater.
Q: What are the operating temperature ranges for this cable?
A: It is suitable for fixed installations from -50°C to 80°C and for flexible applications from -35°C to 80°C.
Q: What is the maximum continuous operating temperature of the conductors?
A: The conductors can operate continuously at up to 90°C.
Q: What is the short-circuit temperature rating?
A: The cable can withstand short-circuit conditions up to 250°C.
Q: Is this cable flame retardant?
A: Yes, it meets EN/IEC 60332-1-2 standards for flame retardancy.
Q: How does the cable perform under oil and chemical exposure?
A: It is oil resistant and designed to withstand exposure to industrial chemicals common in port and shipyard environments.
Q: Can the cable operate in UV and ozone-rich environments?
A: Yes, its PCP outer sheath is UV-resistant and ozone-resistant, ensuring long-term durability.
Q: Is the cable seawater resistant?
A: Absolutely; it is engineered to be seawater resistant, making it ideal for marine and coastal applications.
Q: What is the torsional stress rating of the cable?
A: The cable can handle torsional stresses up to ±50° per meter, ensuring performance during continuous twisting.
Q: What is the permanent tensile strength of the cable?
A: It has a permanent tensile strength of 30 N/mm², which supports high mechanical loads.
Q: What is the recommended bending radius for fixed installations?
A: The minimum bending radius for fixed installations is 4 times the cable diameter (4×D), according to VDE 0298-3.
Q: What is the recommended bending radius for flexible installations?
A: For flexible installations, the bending radius is recommended to be 5 times the cable diameter (5×D).
Q: What bending radius is recommended for S-type directional changes?
A: A minimum of 20 times the cable diameter (20×D) is advised for S-type directional changes.
Q: What is the test voltage for this cable?
A: It is tested at 3.5KV to ensure high-quality electrical insulation and performance.
Q: How does the cable reduce electrical losses?
A: Its use of very finely stranded, tinned copper results in low conductor resistance, thus minimizing power losses.
Q: What standards does this cable comply with?
A: It meets numerous standards, including DIN VDE 0250-814, VDE Reg. Nr. 7519, DIN VDE 0298-3, DIN VDE 0207-20/21, DIN EN 60228/IEC 60228, DIN VDE 0298-4, DIN EN 60811-404/IEC 60811-404, and DIN EN 60332-1-2.
Q: How is this cable suited for E-RTG crane applications?
A: Its high mechanical flexibility and durable construction ensure reliable operation even in the rigorous conditions faced by Electrified Rubber Tyred Gantry cranes.
Q: Does the cable support automated port systems?
A: Yes, with its optional fiber-optic integration, it facilitates real-time data transmission and monitoring for automated port and shipyard systems.
Q: How does the cable handle rapid reeling operations?
A: It is engineered for high-speed reeling with no inherent speed restrictions up to 240 m/min; for speeds above this, consultation with the manufacturer is recommended.
Q: What maintenance practices are recommended for this cable?
A: Regular visual inspections, adherence to bending radius guidelines, and proper tension management are essential to ensure its longevity.
Q: How does this cable contribute to energy efficiency?
A: By minimizing electrical losses through its low resistance conductors and efficient design, it enhances overall system energy efficiency.
Q: What installation support is provided for this cable?
A: Detailed installation guidelines and technical support are available from the manufacturer to ensure optimal performance and safe handling.
Q: How does the cable perform in extreme climatic conditions?
A: Its robust construction enables reliable performance in a wide range of temperatures and environmental conditions, from severe cold to intense heat, as well as exposure to corrosive elements.
Q: Why is the CORDAFLEX XPRT (N)SHTOEU cable an excellent choice for port and shipyard operations?
A: Its superior mechanical durability, environmental resistance, and integrated data capabilities make it an ideal solution for the demanding conditions of port, shipyard, and E-RTG crane applications.
Q: What benefits does the integrated fiber-optic option offer?
A: It allows for simultaneous power and data transmission, enabling real-time monitoring, predictive maintenance, and improved system automation.
Q: How does the cable ensure safety during high-stress operations?
A: Its flame retardant properties, compliance with international standards, and robust insulation minimize risks during high-stress electrical and mechanical operations.
Q: What overall advantages does the CORDAFLEX XPRT (N)SHTOEU cable provide?
A: It offers a unique combination of flexibility, durability, and integrated communication, ensuring reliable low voltage power and enhanced operational efficiency in E-RTG systems and other industrial applications.
